NKGP 560 & KGP 860General AviationEnhanced Ground Proximity Warning SystemPilot’s GuideB

6Rev 5 Jul/2004 KGP 560/860 Pilot's Guide AIRCRAFT ALTITUDEIn addition to the altitude information provided by the GPS, th

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 7On some terrain displays, an indication of MSL or GSL altitude willappear. This altitude is the refer

8Rev 5 Jul/2004 KGP 560/860 Pilot's Guide Regional Database: Americas (shaded areas)Regional Database: Atlantic (shaded ar

Rev 7 Oct/2005 KGP 560/860 Pilot's Guide 9Regional Database: Pacific (shaded areas)Data for known obstacles such as towers, buildings, antennas,

10Rev 5 Jul/2004 KGP 560/860 Pilot's Guide Functions and Featuresnated and a message will be displayed indicating “Warning

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 11Functions and FeaturesThe following figure shows the Terrain Display color patterns when theaircraft

12Rev 5 Jul/2004 KGP 560/860 Pilot's Guide The following figure shows the Terrain Display color patterns when theaircraft

Installations without a heading input into the KGP 560/860 will eitherhave a NORTH oriented or BLANK display when on the ground.Depending upon configu

14Rev 5 Jul/2004 KGP 560/860 Pilot's Guide NOTE: Green colors indicating terrain/obstacles below the aircraft areNOT shown

GA-EGPWS “Peaks” Terrain Display at 12,000 feet near Seattle, WA “LOOK-AHEAD” ALERTING AND WARNINGUsing aircraft position, altitude and flight path i

The information contained in this manual is for reference use only. Ifany information contained herein conflicts with similar informationcontained in

16Rev 5 Jul/2004 KGP 560/860 Pilot's Guide When the “Look-Ahead” function detects a terrain or obstacle threatapproximatel

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 17Runway Field Clearance Floor (RFCF)EXCESSIVE RATE OF DESCENT ALERTING ANDWARNINGThe KGP 560/860 GA-EG

18Rev 5 Jul/2004 KGP 560/860 Pilot's Guide The following graph represents the envelope of protection provided forExcessive

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 19INADVERTENT DESCENT / LOSS OF ALTITUDE AFTERTAKE-OFFThe KGP 560/860 GA-EGPWS uses known runway positi

20Rev 5 Jul/2004 KGP 560/860 Pilot's Guide GA-EGPWS ALTITUDE MONITORINGThe KGP 560/860 GA-EGPWS monitors the various altit

flaps are not in landing configuration. When the aircraft passes below300 feet with flaps down, and the gear is up, a Gear Up aural “CautionGear” is

22Rev 5 Jul/2004 KGP 560/860 Pilot's Guide Excessive Bank Angle Alert EnvelopeFunctions and Features

Rev 6 Jan/2005 KGP 560/860 Pilot's Guide 23NORMAL PROCEDURESGA-EGPWS SYSTEM SELF-TESTPrior to flight, the system should be tested for proper ope

24Rev 6 Jan/2005 KGP 560/860 Pilot's Guide Pressing the Self-Test switch as the Level One Self-Test is completedwill initiat

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 25RECOMMENDED PROCEDURES FOR GA-EGPWSWARNINGS IN FLIGHT“PULL UP”If in Instrument conditions or at night

KGP 560 & KGP 860Enhanced Ground Proximity Warning SystemTABLE OF CONTENTSINTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

26Rev 5 Jul/2004 KGP 560/860 Pilot's Guide RECOMMENDED PROCEDURES FOR GA-EGPWSALERTS IN FLIGHTNormal Procedures“Terrain Ah

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 27ADDITIONAL INFORMATIONAUDIO MESSAGE PRIORITYOnly ONE message is produced at any one time.The highest

28Rev 5 Jul/2004 KGP 560/860 Pilot's Guide Note 1: These are the only voices that can interrupt.Note 2: The preface voices

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 29Note 5: Voice message may be disabled depending upon configuration.Note 6: KGP 860 only, messages may

30Rev 5 Jul/2004 KGP 560/860 Pilot's Guide KGP 560/860 CONTINUED AIRWORTHINESS ANDDATABASE UPDATE PROCEDURESNormal mainten

Rev 5 Jul/2004 KGP 560/860 Pilot's Guide 31KGP 560/860 PRODUCT SUPPORTCustomer Support:1-800-712-0400To order database updates, contact Navigati

32Rev 5 Jul/2004 KGP 560/860 Pilot's Guide Intentionally left blankAdditional Information
